High temperature 25A Auto Blade Fuse 32V , Plug-In Fuse For Machine
تفاصيل المنتج:
| مكان المنشأ: | Dongguan,Guangdong,China |
| اسم العلامة التجارية: | UCHI |
| إصدار الشهادات: | ROHS,SGS,CTI,UL |
| رقم الموديل: | GBC |
شروط الدفع والشحن:
| الحد الأدنى لكمية: | 5000PCS |
|---|---|
| الأسعار: | Negotiable |
| تفاصيل التغليف: | Bulk |
| وقت التسليم: | 3-7 days |
| شروط الدفع: | T/T,Paypal,Western Union,Money gram |
| القدرة على العرض: | 5000,000,000PCS Per Month |
|
معلومات تفصيلية |
|||
| تسليط الضوء: | mini blade car fuses,micro blade fuse,micro blade fuse |
||
|---|---|---|---|
منتوج وصف
High temperature 25A Auto Blade Fuse 32V , Plug-In Fuse For Machine
Quick Details
With "Diffusion Pill Technology'" the East Europe auto blade Fuse provides excellent time delay characteristics and low heat dissipation. Designed and patented by Littelfuse, the MAXI fuse is ideal for motor powered applications which have large inrush currents.
1. Structure and size (unit: mm)
2. Mark and Appearance
2.1 The mark on the fuse should be clear
2.2 There should be the following marks on the both caps of fuse
A:Rated Current
2.3 The appearance of the fuse should be clean and have no stain , oxidizing , etc . The plastic crust should not have been broken , polluted etc.
3. Electrical characteristics
3.1 Test Condition
All electrical tests are conducted at an ambient temperature of 25±5℃.
3.2 Color Mark:
|
Current(A) |
Color |
|
5 |
YELLOW |
|
8 |
WHITE |
|
15 |
RED |
|
20 |
YELLOW |
|
25 |
BLUE |
|
30 |
REEN |
3.3. Time-Current Characteristics
|
Rating |
Blowing Time |
|
150% |
<1H |
|
250% |
<1 Min |
Competitive Advantage
1. Factory supply directly
2. Completed certificates such as UL,VDE,SGS,etc and high quality available
3. Quick delivery
4. Best after-sales services
5. OEM & ODM available
